EURO 6 Honeycomb Ceramic Catalyst Passenger Car
Product Description
Emission Aftertreatment System Upgrade Requirements
Modern vehicle exhaust aftertreatment systems comprise advanced
technologies installed downstream of the combustion engine to
significantly reduce harmful emissions. These systems integrate
multiple components:
Core Aftertreatment Technologies
• TWC (Three-Way Catalyst): Simultaneously reduces NOx, CO, and HC
in gasoline engines
• SCR (Selective Catalytic Reduction): Targets NOx reduction in
diesel applications
• DOC (Diesel Oxidation Catalyst): Converts CO and HC into CO₂ and
H₂O
• DPF/GPF (Diesel/Gasoline Particulate Filter): Captures 99% of
soot particles
• ASC (Ammonia Slip Catalyst): Prevents NH₃ leakage from SCR
systems
Catalytic Conversion Process
When exhaust gases (containing NOx, CO, and HC) flow through the
catalytic converter:
1. Redox Reactions occur on the catalyst surface
2. Toxic compounds transform into environmentally safe outputs:
◦ Nitrogen oxides (NOx) → Nitrogen (N₂) + Oxygen (O₂)
◦ Carbon monoxide (CO) → Carbon dioxide (CO₂)
◦ Hydrocarbons (HC) → Water (H₂O) + CO₂
System Upgrade Drivers
✔ Stricter emission standards (Euro 6d/China VI/EPA Tier 3)
✔ Improved catalyst formulations (Pd/Rh-based TWCs, Cu/Zeolite SCR)
✔ Advanced filter technologies (SiC DPFs, asymmetric-cell GPFs)
2.Chemical Composition:
Chemical Composition | Alumina Ceramic | Mullite | Cordierite | Cordierite porous | Quartz |
porous | dense | Porcelain |
SiO2 | 41-44 | 26-29 | 59-59 | 48-52 | 65-68 |
Al2O3 | 50-53 | 67-70 | 24-27 | 34-37 | 25-30 |
MgO | ≤0.4 | ≤0.4 | 7-8 | 8-9 | ≤0.5 |
Alkali | ≤4 | ≤1.3 | ≤3 | ≤1.3 | ≤5 |
3 .Geometric data:
Size | 150×150×300mm | 150×150×300mm | 150×150×300mm | 150×150×300mm |
Channels | 25 x 25 | 40 x 40 | 50 x 50 | 60 x 60 |
Channel width | 4.9mm | 3.0mm | 2.4mm | 2.0mm |
Inner walls | 1.0mm | 0.7mm | 0.6mm | 0.45mm |
Spec area | 540m²/m³ | 825m²/m³ | 1050m²/m³ | 1310m²/m³ |
Void | 67% | 64% | 63% | 64% |
4.Physical Data
Materials | Units | Alumina ceramic | Mullite | Cordierite | Cordierite porous | Quartz |
| | |
porous | dense | porcelain |
Density | g/cm3 | 2.7 | 2.1 | 2.5 | 1.9 | 2.3-2.5 |
Bulk Density | Kg/m3 | 965 | 832 | 871 | 778 | 889 |
Thermal Expansion Coefficient | 10-6 /°C | 6,2 | 3,5 | 3,4 | 6,2 | 4,8 |
Specific heat Capacity | J/KgK | 992 | 998 | 942 | 1016 | 897 |
Thermal Conductivity | W/mK | 2.79 | 2.42 | 1.89 | 1.63 | 1.37 |
Resistance to Fluctuated Temp | Max K | 500 | 550 | 500 | 600 | 500 |
Softening Temperature | °C | 1500 | 1580 | 1320 | 1400 | 1380 |
Max. temperature | °C | 1400 | 1480 | 1200 | 1300 | 1280 |
Average Thermal Capacity | KWh/m3K | 0.266 | 0.231 | 0.228 | 0.219 | 0.222 |
Porosity Ratio | % | 0.8 | 26 | 0.4 | 15 | 0.6 |
Acid Resistance | % | 0.2 | 2.5 | 5 | 16.7 | 0.3 |
All the data is only for reference, specific sizes and hole shapes
are according to customers' requirements.
